Echo 2

• Free U.S ground shipping and 30-day money back guarantee on all orders•

Features

The Echo 2 is a high-end personal mixer and a USB audio interface. With innovative touch panel controls and premium microphone preamps, the Echo 2 is perfect for live performance and for recording.

The Echo 2 features touch controls, built-in studio grade preamps, and a compact, portable design. You don't need a separate preamp or direct box - simply connect your instrument or microphone to the Echo 2, and mount the Echo 2 on your microphone stand using the included bracket. Complete control of your mix is right at your fingertips.

The Echo 2 is great for recording, mixing, mastering, or just listening to a playlist. The separate headphone and main outputs are also ideal for DJ software.

The Echo 2 is a versatile creative tool, with audio quality comparable to interfaces costing hundreds of dollars more.

Hardware Features

  • USB 2.0 high speed interface with 9’ cable
  • Power from USB* or included international AC adapter
  • Intuitive, simple touch panel controls
  • Selectable microphone, balanced line, or high-impedance instrument inputs
  • EZ Trim - Precisely set your inputs to the optimal level with the touch of a button
  • Low noise (-129 dBu EIN) studio grade mic preamps
    • Up to 75dB of gain
    • Switchable +48V phantom power
    • Two female XLR to male ¼” TRS cables included
  • Separate main and headphone outputs with adjustable volume and monitor levels and main mute
  • Supports full duplex 2 channels in, 4 channels out operation at 24 bit, up to 192kHz sample rate
  • Near zero latency hardware monitoring
  • Adjustable mic stand bracket included
  • Durable aluminum case

*USB 3.0 or Mac, AC adapter may be needed for +48V with PC USB 2.0 ports

Software Features

  • Supports all major pro audio software:
    • Low latency ASIO 2.0
    • Windows MME, DirectSound, WASAPI, WDM/KS
    • Mac OS X CoreAudio

Analog Inputs

  • Frequency response: 10Hz – 20kHz, +/- 0.1dB
  • Dynamic range: 115dB A-weighted
  • THD+N: .001% A-weighted

Analog Outputs

  • Frequency response: 10Hz – 20kHz, +/- 0.1dB
  • Dynamic range: 113dB A-weighted
  • THD+N: .0015% A-weighted

System Requirements

  • PC System Requirements:
    • Windows XP with SP3 (32 bit)
    • Windows Vista with SP2 (32 bit and 64 bit)
    • Windows 7 (32 bit and 64 bit)
    • Windows 8 (32 bit and 64 bit)
    • USB 2.0 or USB 3.0 port
  • Mac System Requirements:
    • Mac OS X 10.6.8 or later

Product Specifications

Echo Digital Audio uses only specifications of production units. While other companies quote specs of their converters alone in laboratory settings, the numbers you see on this page represent the actual unit in your hands. Since people often rely heavily on specs when deciding what gear to buy, we like to bring you numbers that really mean something.

Analog Inputs

  • Two ¼" TS/TRS inputs with selectable microphone, balanced line, or high-impedance instrument.
  • Switchable +48V phantom power
  • EZ Trim - Precisely set your inputs to the optimal level with the touch of a button
  • Low noise (-129 dBu EIN) studio grade mic preamps, up to 75dB of gain
  • Input impedance - Mic: 1.8K ohms, Line: 20K ohms, Instrument: 1Meg
  • Two female XLR to male 1/4" TRS cables included
  • Frequency response: 10Hz – 20kHz, +/- 0.1dB
  • Dynamic range: 115dB A-weighted
  • THD+N: .001% A-weighted

General Converter Specs

  • 128x oversampling converters
  •  Low jitter with less than 4 ps internal clock
  • 24 bit data resolution maintained throughout signal path
  • Multiple standard sampling rates supported: 44.1k, 48k, 88.2k, 96k, 192K

Analog Output

    • Two ¼" TS/TRS outputs
    • Frequency response: 10Hz – 20kHz, +/- 0.1dB
    • Dynamic range: 113dB A-weighted
    • THD+N: .0015% A-weighted
    • Line output impedance: 120 Ohm
    • One ⅛" headphone output with adjustable volume and monitor levels and main mute
    • Max output level on the line and headphones: 10dBu
    • Max output current headphones: 60mA
    • Headphone output impedance: 1 Ohm
    • Supports full duplex 2 channels in, 4 channels out operation at 24 bit, up to 192kHz sample rate
    • Near zero latency hardware monitoring

Dimensions

  • Only 5.4” x 3.6” x 1” (137mm x 92mm x 26mm) – 0.5 lbs

Drivers

Windows Drivers

Operating System Driver File Size Date Posted Documentation
Windows (Windows 7 & Windows 8) 1.61 download 2.23 MB 01/04/2013 Readme
Windows (Versions) 1.56 download 1.90 MB 07/18/2012 Readme

Mac OS X Software

No drivers required.

Manuals

Operating System Version File Size Date Posted
Windows 1.2 download 647 KB 06/13/2012
Macintosh 1.2 download 647 KB 06/13/2012

Reviews

There are no reviews available.

Product Comparison

Specification Echo 2 AudioFire Pre8 AudioFire 4 AudioFire 12 Layla3g Mia Midi

*Universal inputs support mic, guitar, & line level signals over XLR or 1/4" (balanced TRS or unbalanced TS) cables. Meters, trim knobs, & phantom power switch are provided.

**Analog inputs for the AudioFire Pre8 feature Mic phase, Impedance, Pad, Hi-Pass, Direct Input and separate Phantom Power buttons.

All cards have output levels for analog outputs and monitors that can route from any input to any output.
All cards support internal input clock.

Specifications subject to change without notice.
Analog Inputs 2 universal* 8 universal* 2 universal*,
2 ¼" (TRS)		 12 ¼" (TRS) 2 universal* 2 ¼" (TRS)
Analog Outputs 2 ¼" (TRS), 1 ⅛" (TRS) 8 ¼" (TRS) 4 ¼" (TRS) 12 ¼" (TRS) 8 ¼" (TRS) 2 ¼" (TRS, 8 virtual)
Microphone Preamps 2 Digital Trim, EZ Trim 2 Analog Trim 2 Analog Trim 2 Analog Trim
Selectable +4 dBu -10 dBV
Digital Interface ADAT, S/PDIF S/PDIF ADAT, S/PDIF S/PDIF
Sync Word, S/PDIF & ADAT S/PDIF Word Word, S/PDIF, ADAT & MTC S/PDIF
Midi
Sample Rates Up to 192 kHz Up to 96 kHz Up to 96 kHz Up to 192 kHz Up to 96 kHz Up to 96 kHz
Dynamic Range 115dB in, 113dB out; (A-weighted) 112dB in, 113dB out; (A-weighted) 112dB in, 114dB out; (A-weighted) 113dB in, 114dB out; (A-weighted) 113dB in, 114dB out; (A-weighted) 106dB (A-weighted)
Other Independent headphone output; stand-alone operation 2 headphone outputs, main volume control headphone output; bus power supported 12 channels full duplex 192kHz headphone output 8 virtual outputs
Interface USB 2.0 or 3.0, iPad via Apple's camera connection kit FireWire FireWire FireWire PCI PCI
Price $399.00 $599.95 $599.00 $499.00 $299.00
